Thông tin sản phẩm
Mã hàng: RG-EW1200G
Bảo hành: 36 tháng
Hãng sản xuất: Ruijie
Mô tả sản phẩm
THÔNG SỐ
Wireless specifications | 2.4GHz 2*2: maximum rate 400Mbps; 5GHz 2*2: maximum rate 867Mbps |
Antenna: External 6dBi non-removable omnidirectional antennas | |
Support 802.11a/b/g/n/ac/ac Wave2, MU-MIMO | |
Frequency band: Independent 2.4GHz and 5GHz modules, supporting dual frequency integration | |
Support beamforming | |
Wi-Fi channel: | |
2.4GHz Channel: 1,2,3,4,5,6,7,8,9,10,11,12,13 | |
5GHz Channel: 36,40,44,48,149,153,157,161,165 | |
Ports | 1 10/100/1000M WAN port(Auto MDI/MDIX) |
3 10/100/1000M LAN ports(Auto MDI/MDIX) | |
1 blue system LED indicator, 4 network port LED indicators | |
1 device pairing/factory reset button | |
1 power input interface | |
Physical specifications | Dimensions:220x140x36mm (W×D×H, excluding antennas) |
Weight:0.98kg(entire equipment including packaging) | |
Power supply | Power specification: DC12V 1.5A |
Maximum power: <14W | |
Certification | CCC,SRRC |
Operating environment | Operating temperature: 0-45℃ |
Storage temperature: -40-70℃ | |
Operating humidity: 5%-95%RH (non-condensing) | |
Storage humidity: 5%-95%RH (non-condensing) | |
Main features | Routing mode: PPPoE / DHCP / static IP; relay mode: wired relay / wireless relay |
Obtain PPPoE account from the old router | |
Wi-Fi dual-band separation/ integration | |
Guest Wi-Fi; smart home Wi-Fi; wireless network isolation | |
Static DHCP address | |
Virtual server: port mapping, DMZ, etc. | |
DDNS: Oray | |
UPnP | |
Network security | Wireless security: WPA-PSK/WPA2-PSK encryption |
ARP protection: IP/MAC binding | |
SSID hiding | |
Preventing rogue devices (Blacklist/whitelist) | |
Internet access control | |
Advanced features | Reyee Mesh: Supports zero-configuration networking of multiple devices, and supports automatic switching between wired and wireless networking for multiple devices |
Wi-Fi optimization: Wi-Fi roaming, 5G priority, acceleration mode, channel adjustment, power adjustment, roaming sensitivity adjustment | |
Bandwidth management: hardware NAT, intelligent bandwidth allocation | |
Auto network inspection, fault diagnosis | |
Software upgrade: Automatic & manual cloud software upgrade | |
Management mode | Local web page |
Cloud management: MACC cloud platform | |
Ruijie Cloud app: iOS version, Android version |
